Sentinel 2 SR¶
Remote Sensing · Climate Engine ID: SENTINEL2_SR
Dataset specifications¶
| Spatial resolution | 10m |
|---|---|
| Temporal frequency | 5 Day |
| Geographic coverage | Global |
| Period of record | 2015–Present |
Overview¶
Reflectance data from the Copernicus Sentinel-2 satellite is available for top-of-atmosphere(TOA) and for the earth surface reflectance(SR) in visible, near, and short wave infrared bands. Several vegetation indices are constructed from these bands such as NDVI, EVI, NDSI, NDWI.
Variables¶
34 variables available.
| Variable | Units |
|---|---|
| AVI | — |
| Blue | — |
| Blue/Nir ratio | — |
| BSI | — |
| DVI | — |
| EVI | — |
| False Color | — |
| FCVI | — |
| Green | — |
| Green/Blue ratio | — |
| Green/Nir ratio | — |
| Green/Red ratio | — |
| MCARI2 | — |
| MSAVI | — |
| NBR | — |
| NDCI (Red_Edge,RED) | — |
| NDRE | — |
| NDSI | — |
| NDVI | — |
| NDWI (Green/SWIR2) | — |
| NDWI (Green/NIR) | — |
| NDWI (Green/SWIR1) | — |
| NDWI (NIR/SWIR1) | — |
| NDWI (SWIR1/Green) | — |
| NIR | — |
| Red | — |
| Red/Blue ratio | — |
| Red/Nir ratio | — |
| SAVI | — |
| SWIR1 (1.610 um) | — |
| SWIR2 (2.190 um) | — |
| SWIR3 (1.375 um) | — |
| True Color | — |
| VSDI | — |
Source and access¶
Source catalog: Earth Engine Catalog
Earth Engine assets¶
COPERNICUS/S2_SR_HARMONIZED
Usage and attribution¶
Processing notes¶
- ClimateEngine applies the Cloud Score+ cloud mask produced by Google. We use the 'cs' band which provides 'pixel quality score based on spectral distance from a (theoretical) clear reference' set at a quality score of 60.
References¶
- Drusch, M., Del Bello, U., Carlier, S., Colin, O., Fernandez, V., Gascon, F., Hoersch, B., Isola, C., Laberinti, P., Martimort, P., Meygret, A., Spoto, F., Sy, O., Marchese, F., & Bargellini, P. (2012). Sentinel-2: ESA's Optical High-Resolution Mission for GMES Operational Services. Remote Sensing of Environment, 120, 25-36. https://doi.org/10.1016/j.rse.2011.11.026
Terms of use¶
The use of Sentinel data is governed by the Copernicus Sentinel Data Terms and Conditions.
